Automatic Tube Cutting Machine| Disc blade|QG03

Adopted with the advanced CNC digital controlling system, automatic Tube Cutting Machine can make the production line free from attendance and make it fully data-based. This machine can feed, cut and unload materials automatically. Equipped with servo motor, the machine can cut the tube at an accurate length. Controlled by the digital system, the production process is stable and can be adjusted automatically. More than one tube can be cut at one time, and thus the production is efficient. The biggest highlight of this equipment lays on its five sets of full-gear transmission heads, which are optimized products based on four sets of transmission equipment in Taiwan (factory experimental cutting experience: ø50 round steel, can be cut in 25 seconds.) It applies to cut metal materials with different cross-sections, such as ordinary steels, stainless steels, copper and aluminum, especially Metal Tubes. It is the high-quality equipment for the mass production of steel furniture, tubes, sports equipment, tourism and leisure products, cars, motorcycles, bicycles, baby carriages decoration, stainless steel decoration and machine processing.

Main characteristics

1. This machine is equipped with continuously variable transmission vertical cutter，automatic cutting and hydraulic cylinder automatic clamping device. It runs smoothly, lightly and efficiently.
2. Horizontal clamping makes workpieces clamped stably, with low noise and low pollution.
3. The servo motor drives the ball screw, and the feeding carriage moves on the linear guide rail (not on the cylindrical guide column), featuring high feeding accuracy, fast speed, stable feeding. The cut surface is smooth and does not generate heat. The auxiliary clamp is equipped with a floating function to prevent the pipes from being scratched on the main clamp.
4. Equipped with high-strength disc blades, it features fast cutting speed, smooth cross-section and no burrs.
5. It can automatically stop when there is no material. It has the disc blade protection，automatic lubrication and cooling function.
6. It can deal with the tailings and cut the tailings shorter than the workpieces, minimum to 50 mm, which will economize the materials.
7. It is equipped with the self-lubricating bearing, which lubricates the connecting shaft automatically and protects the machine.
8. The all-gear head adopts a horizontal motor, with five sets of all-gear meshing, which is more stable, more wear-resistant, and has stronger head power than the ordinary all-gear heads on the current market with four-set structures and four-speed regulation.
9. The cooling system makes the machine work for a long time and increases its service life.
10. The column used for disc blade adopts a linear guide rail type. The guide rail surface is scraped by professional equipment, which is more accurate and durable.
11. The oil circulation cooling system ensures the reliability and durability of the components and extends their service life.
12. All of the mechanical movement structures and parts are equipped with a numerical control self-contained oil lubrication system, which ensures that the mechanical structure movement is maintenance-free for a long time and has an extremely long service life.

Technical parameters
