Straightening And Cutting Machine For Mineral Insulated Cable （MI cable）(rotary cutting without burrs)

This machine is suitable for straightening and cutting Mineral Insulated Cable, RTD or metal sheathed elements with diameters ranging from 1.0 to 10 mm . A servo motor precisely controls the length, allowing for unlimited length selection.

Basic parameters

1. Voltage: 220V/50-60HZ
2. Power: 5KW
3. Dimensions: 1750*600*1650mm
4. Weight : 320 kgs
5. Accessories : Comes with molds for four different diameters and two blades.

Applicable materials

1. Minimum/maximum diameter : 1.0~10mm （standard machines）
2. Metal tube wall thickness: ≤1mm
3. Compatible materials: All kinds of metal materials.
4. Production speed: φ3*100 with a 10mm groove on one side, approximately 5 seconds per piece.

Cutting ability

1. Length tolerance: The servo motor precisely controls the length, with a tolerance of ±0.5mm.
2. Burr-free cutting
3. Tool type: Carbide tools

Grooving of the sheath (key point )

1. Adjustable cutting depth
2. No effect on magnesium oxide layer
3. Slot length: 0 to infinity
4. Groove width: 0.1~1mm
5. Grooving tools: blades

Straightening ability

1. Number of rollers: 2
2. Adjustable pressure
3. Diameter switching: For example, switching from 1 mm to 6 mm takes approximately 5 minutes, manual adjustment.

Control Interface

1. Language: Chinese and English, other languages can be customized.
2. Length programmable
3. The program can be stored
4. The controller is independently developed and is not a PLC.
